The hardware is the easy part. You can buy a beautiful $3,000 glowing wall, roll it out at the show, and still have it look cheap — because the one thing that makes or breaks a backlit display isn't the frame, it's the artwork file behind it. Light shines through the graphic, which is unforgiving: it exaggerates low resolution, muddies dark clutter, and washes out anything low-contrast. Get the file right and the same wall looks like a flagship brand.

This is the setup we wish every customer had before they sent artwork. Two parts: the technical specs that must be correct, and the design choices that only matter because the thing is lit from behind.

Part 1 — The specs that must be right

Miss any of these and the file either can't be printed cleanly or comes back looking wrong. Our free artwork check catches most of it, but building it right first saves you a re-do:

  • Format: print-ready PDF. Flattened, single file, built at the size on the template.
  • Colour: CMYK only — no RGB, no HEX. Screens are RGB; printing is CMYK, and RGB files shift colour when converted.
  • Resolution: 130–300 dpi at 100% scale. Large walls are viewed from a distance, so 130 dpi at full size is fine; small counters and close-viewed panels lean to 300.
  • Bleed: 20mm. The image must extend 20mm past the finished edge so it wraps into the frame's silicone channel with no white gap showing.
  • Safe area: keep key content inside the 15mm margin. Logos, text and anything you can't lose stay inside the safe zone, away from where the fabric meets the frame.
  • Fonts: outline them all. Convert type to outlines/curves so nothing reflows or substitutes on our end.
  • Brand colours: PANTONE+ Solid Coated. Specify critical brand colours as Pantone (Solid Coated) so we can match them, not guess from CMYK.

Start from our size templates — they have the bleed, safe area and finished size already set, so you're building into the right box from the first click.

Part 2 — Designing for the light (the part most guides skip)

A backlit graphic is not a big poster. It's lit from behind, and that changes what works:

Contrast is everything. Backlighting blows out subtle, low-contrast areas — pale-on-pale detail disappears in the glow. Push your contrast further than you would for print. Bold shapes, clear type and strong colour separation read beautifully; delicate gradients and faint watermarks vanish.

Whites and lights glow brightest. Light passes most through pale areas, so a white or light background becomes a genuine light source — perfect for making a logo pop. If your brand is light, lean into it.

Deep colours stay rich, but dark ≠ detail. Blacks and deep tones block light and read as solid and premium — great for drama. Just don't hide important detail in dark areas, because it won't be lit and will disappear.

Use genuinely high-resolution images. Backlighting magnifies flaws — JPEG artifacts, upscaled logos and soft photos all look worse lit than they do on screen. Source art at full size.

Expect a slight colour shift, and plan for it. Dye-sublimation onto fabric renders colour a touch differently than a backlit screen preview. That's normal — it's exactly why we send a proof, and why Pantone references matter for brand colours.

Where to put the important stuff

Design for how people actually stand in front of it. Keep your logo and headline in the upper-middle "sightline" band — roughly eye-to-head height — where they clear a counter, a laptop, and the crowd standing at your stand. Anything critical near the bottom edge gets blocked by people and furniture; anything near the outer edges risks the frame. Push the hero message up and central, let backgrounds and texture run to the bleed.

Getting the colour you expect

Two habits remove almost all colour surprises. First, build in CMYK from the start so you're seeing print colour, not screen colour, as you design. Second, call out your brand colours in PANTONE+ Solid Coated — that gives us a fixed target to match rather than an interpretation. Then the proof does the rest: we send it before anything prints, you sign off on layout, colour and sizing, and nothing goes to production until you're happy.

How to send us your file

After you order, send your print-ready PDF one of two ways: upload directly (up to 200MB) at checkout, or send via WeTransfer, SendSpace, Google Drive or Dropbox to enquiry@wildcowvisual.com.au. Include your order number and the size/template you designed to. We check every file free before printing and flag anything that needs fixing.

Quick pre-flight checklist

Before you send, confirm:

  • Built to the correct size template, with 20mm bleed
  • CMYK colour, brand colours tagged PANTONE+ Solid Coated
  • Images 130–300 dpi at 100%, sourced at full resolution
  • Key content inside the 15mm safe area, hero message in the upper-middle band
  • All fonts outlined, elements embedded
  • Exported as a flattened, print-ready PDF

Frequently asked questions

What file format and colour mode do you need for a backlit SEG display? A flattened, print-ready PDF built in CMYK (not RGB or HEX), at 130–300 dpi at 100% scale, with 20mm bleed and fonts outlined. Tag brand colours as PANTONE+ Solid Coated so they can be matched.

Why does my artwork look different printed than on my screen? Screens are backlit RGB; fabric is printed in CMYK by dye-sublimation, so colour renders slightly differently. Building in CMYK and specifying Pantone references keeps it close, and the proof we send before printing lets you confirm colour before production.

How much bleed and safe area do I need? Add 20mm of bleed beyond the finished size so the graphic wraps into the frame channel with no white gap, and keep all important content inside a 15mm safe margin so nothing is lost where the fabric meets the frame. Our size templates have both built in.

What resolution should the images be? 130–300 dpi at 100% (final) size. Large walls viewed from a distance are fine at ~130 dpi; smaller, close-viewed pieces like counters look best nearer 300. Always source images at full size — backlighting exaggerates low resolution.

How should I design differently because it's backlit? Push contrast harder than you would for print, use light/white areas to make elements glow, keep important detail out of very dark zones, and use genuinely high-res images. Light shines through the graphic, so subtle low-contrast detail washes out.

Do you check the artwork before printing? Yes — every file gets a free artwork check, and we send a proof for you to approve. Nothing prints until you sign off on layout, colour and sizing.

Can you fix or set up my artwork if I only have a logo? Send us what you have and your order details — we'll tell you what's workable and what's needed. For full design we can advise on options; at minimum we'll make sure whatever you supply is set up correctly before printing.

The bottom line

Your display will only ever look as good as the file behind it. Nail the seven specs, design for the light instead of for a screen, keep your hero message up where people can see it — and let the proof catch the rest. Do that, and a backlit SEG wall does exactly what you bought it for: makes your brand look bigger than it is.

Start from the templates, and email us your file when it's ready.
